GB Milton roy dosing pump

Release time:2019-11-25  Browse times:665

G series Milton Roy dosing pump


1574661579675039.jpg 1574661579256449.jpg 1574661582686294.jpg




Main Technical Characteristics

• Flowrate up to 1800L/H
• Pressure up to 12 bar
• Suction lift: up to 3 m water
• Maximum suction pressure: 2 bar
• Accuracy: ± 2% of rated flow from 10% to 100% stroke
• Maximum temperature of pumped liquid: 40℃



Features & Benefits

Liquid End

• Mechanical actuated diaphragm design
• Eliminate contour plates,easy for material pass
• PVC, PVDF & 316SS liquid end material
• High viscolity,slurry application
• Self-cleaning suction/discharge check valve


Drive End

• Variable eccentric drive mechanism for smooth sinusoidal flow
• Rugged construction designed to withstand tough environments
• Hard-wearing ball bearings to make pump work more stably
• Oil bath lubrication for all of drive components
• Lockable micrometer stroke, adjustment can be adjusted while pump
is running or stopped



Automatic Capacity Control Options

Electrical capacity controller: Accept external control signal to adjust the stroke length
• Power supply: 220V-50Hz, single phase
• Input signal: 4-20mA analog signal
• Output signal: 4-20mA/1-5V analog signal for record display and control system


Varipulse controller: ON/OFF control the three phase motor to adjust the flowrate
• Power supply: 200-240V/50/60Hz, single phase
• Input signal: 4-20mA analog signal / pulse signal / manual


Variable frequency controller: Accept external control signal to adjust the stroke speed
• Power supply: 200-240V/50/60Hz, single phase
• Input signal: 4-20mA analog signal / pulse signal / manual



Applications
Municipal, industrial water and wastewater, swimming pools
and other water treatment process




Structure map

LMI G xq 01.jpg
