Products > Water Treatment Equipment > Automatic Plate Filter Press

Automatic Plate Filter Press

Release time:2022-10-27  Browse times:2706

Automatic Plate Frame Membrane Machine Equipment Belt Filter Press



Overview

Filter press is divided into plate frame filter press and box filter press,it is an intermittent pressure filter equipment for solid-liquid separation of various suspensions.It relies on a co mpaction device to compact the filter plate, and then uses material pump to presses the sus pension material pump into the filter chamber. The filter cloth is used to achieve the purpose of separating solid particles from liquid materials.The structure of the whole machine is simple and the separation effect is good.It is easy to use and has a wide range of applications.It is widely used in coal washing, inorganic salts, mining, alcohol, petroleum, chemical industry.fuel, metallurgy, medicine, food, textile, printing and dyeing, papermaking and sewage treat ment field.



Product description

Our company produces various types of box and plate frame mechanical filter presses, hyd raulic filter presses, diaphragm filter presses, automatic filter presses, quick-opening filter pr esses, and filter press accessories, with reliable quality and complete specifications


1. Specifications : Types of 200, 380, 500, 700, 870, 1000, 1250, 1500, 2000, and various special-shaped filter plates and filter presses.

2.The filtering area is up to 2000m

3. Filter plate material: stainless steel, cast iron, rubber, reinforced polypropylene, glass fiber with high temperature resistance, pp-30 elastomer membrane plate.

4. Liquid flow forms are open flow, dark flow, washable, non-washable, medium feed, corner feed, upper and middle feed and other forms.

5. Filter plate compąction methods are: manual sçrew compaction, electro-mechanical com paction fluid, and hydraulic cylinder compaction. For special requirements of the filter press can be resolved separately.

6. The whole maçhine doęs not include material infusion pumps
and filter cloths. If nece ssary supplies can be specified in the contract.

7. According to the special requirements of customers, our company can produce non standard models and products suitable for your needs.

8. If technical data changes due to model improvements, the actual size at the time of ordering shall prevail.



   1582597568257160.jpg      1582597569390290.jpg

  1583913939158931.jpg    1583913940270553.jpg









Automatic filter press equipment:





Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
